W-SERIES V2D-4X5Z5: 5MP 4-Lens AI Dome Security Camera

Login to see prices
Vendor PAM Distributing
View details

Call: 800-888-8101

Fill Out Customer Application

PN / WS-V2D-4X5Z5 *


V2D-4X5Z5 5MP 4-Lens AI Dome Security Camera

The V2D-4X5Z5 is a rugged 5MP dome security camera designed for dependable, high-detail surveillance in demanding indoor and outdoor environments. Its motorized 2.7–13.5mm varifocal lens provides flexible coverage, while Starlight technology, infrared illumination up to 50 meters, and 130dB true WDR deliver clear video in low light and challenging high-contrast scenes.

Built-in AI analytics support perimeter protection, Smart Motion Detection (SMD), people counting, and face capture. A built-in microphone adds audio monitoring, while triple-stream video and Ultra 265 compression help reduce bandwidth and storage requirements without sacrificing important image detail.

With IP67 weather resistance and IK10 impact protection, the V2D-4X5Z5 is engineered to withstand harsh weather, dust, moisture, and vandalism—making it an excellent choice for commercial buildings, warehouses, campuses, parking areas, retail locations, and other security-critical properties.

Key Features

  • 5MP resolution at up to 2880 × 1620 and 30 fps

  • 4-lens dome camera design

  • Motorized 2.7–13.5mm varifocal lens

  • Starlight technology with 0.002-lux minimum illumination

  • Smart infrared night vision up to 50 meters

  • 130dB wide dynamic range for difficult lighting conditions

  • Built-in AI algorithms

  • Perimeter protection and Smart Motion Detection

  • People counting and face capture analytics

  • Built-in microphone for audio monitoring

  • Triple-stream video output

  • Ultra 265, H.265, H.264, and MJPEG compression

  • MicroSD card slot for onboard recording

  • Automatic infrared-cut filter for accurate day/night imaging

  • IP67-rated weather and dust protection

  • IK10-rated vandal resistance

  • Flexible DC 24V, AC 24V, or high-power PoE operation

Technical Specifications

  • Image sensor: 1/2.7-inch CMOS

  • Maximum resolution: 2880 × 1620 at 30 fps

  • Lens: 2.7–13.5mm motorized varifocal

  • Minimum illumination: 0.002 lux

  • Wide dynamic range: 130dB

  • Infrared range: Up to 50 meters

  • Video compression: Ultra 265, H.265, H.264, and MJPEG

  • Video streams: Triple streams

  • Audio: Built-in microphone

  • Storage: MicroSD card slot

  • Power: DC 24V ±25%, AC 24V ±25%, or PoE (IEEE 802.3bt)

  • Environmental protection: IP67

  • Impact protection: IK10
