Lysora LR100G 5-Port Gigabit Cloud-Managed Router

Centralized Network Management for Growing Businesses

The Lysora LR100G is a compact, cloud-managed Gigabit router designed for small and medium-sized businesses, retail locations, offices, hospitality environments, and professional Wi-Fi installations. It features five Gigabit Ethernet ports, support for up to two WAN connections, and recommended capacity for up to 100 concurrent users.

With routing throughput of up to 600 Mbps in Normal Mode or 1,000 Mbps in Turbo Mode, the LR100G delivers dependable performance for everyday business applications. Integrated cloud management, access-point control, multi-WAN load balancing, VPN connectivity, and user-authentication tools provide a complete foundation for secure and manageable networks.

Key Features

  • 5 Gigabit Ethernet Ports — Includes three dedicated LAN ports, one dedicated WAN port, and one configurable LAN/WAN port.

  • Dual-WAN Support — Connect up to two internet services for load balancing and improved network availability.

  • Gigabit Routing Performance — Supports up to 600 Mbps in Normal Mode and 1,000 Mbps in Turbo Mode.

  • Supports Up to 100 Concurrent Users — Designed for small and medium-sized commercial networks.

  • Cloud, App, and Web Management — Configure, monitor, restart, diagnose, and update the router locally or remotely.

  • Integrated AP Management — Centrally manage compatible wireless access points, client connections, RF settings, roaming, mesh networking, and SSIDs.

  • Routing and AC Operating Modes — Supports up to 32 access points in Routing Mode or up to 300 access points in AC Mode.

  • Multi-WAN Load Balancing — Distributes network traffic across available internet connections.

  • SD-WAN Support — Simplifies secure connectivity between multiple locations.

  • Comprehensive VPN Support — Includes IPsec, WireGuard, OpenVPN, L2TP, L2TP over IPsec, and PPTP options.

  • Guest and Captive Portal Authentication — Supports voucher, account, SMS, QR-code, one-click, and custom cloud portal authentication.

  • Advanced Routing Features — Supports static routing, policy-based routing, URL-based routing, RIP, OSPF, IPv4, and IPv6.

  • Network Security Controls — Includes access-control lists, MAC filtering, IP-MAC binding, security zones, and local attack defense.

  • User and Application Management — Provides application control, flow control, traffic auditing, and user-behavior management.

  • VLAN Support — Create up to 16 VLANs across the LAN interfaces for improved segmentation and organization.

  • Fanless Design — Provides quiet and reliable operation through natural cooling.

  • Desktop or Wall Mounting — Offers flexible placement for a variety of installation environments.

  • NDAA Compliant — Suitable for projects requiring NDAA-compliant networking equipment.

  • 3-Year Warranty — Backed by Lysora’s manufacturer warranty.

Complete Control from the Lysora Cloud

The LR100G provides centralized management for the router, connected access points, and wireless clients. Administrators can remotely monitor device status, adjust Wi-Fi settings, configure client allowlists and blocklists, manage roaming, perform fault diagnosis, and deploy cloud-based software upgrades.

Ideal Applications

  • Small and medium-sized businesses

  • Retail stores and restaurants

  • Offices and professional facilities

  • Hospitality and guest Wi-Fi networks

  • Multi-location businesses

  • Managed wireless networks

  • Captive portal and voucher-based Wi-Fi

  • Remote or branch-office connectivity

  • Networks requiring dual-WAN failover or load balancing

Technical Specifications

  • Ethernet Ports: 5 × 10/100/1000BASE-T

  • Port Configuration: 3 × LAN, 1 × WAN, and 1 × LAN/WAN

  • Maximum WAN Connections: 2

  • Recommended Concurrent Users: 100

  • Maximum Concurrent Sessions: 12,000

  • Routing Throughput: 600 Mbps in Normal Mode; 1,000 Mbps in Turbo Mode

  • AP Capacity: Up to 32 APs in Routing Mode or 300 APs in AC Mode

  • Maximum SSIDs: 8

  • VLAN Support: Up to 16 VLANs across LAN interfaces

  • Processor: Dual-core, 880 MHz per core

  • Memory: 128 MB RAM and 32 MB flash

  • VPN Support: IPsec, WireGuard, OpenVPN, L2TP, L2TP over IPsec, and PPTP

  • SD-WAN: Supported

  • IPv4/IPv6: Supported

  • Management: Lysora Cloud, mobile app, and web interface

  • Maximum Power Consumption: 5W

  • Cooling: Fanless

  • Mounting: Desktop or wall

  • Operating Temperature: 32°F to 104°F (0°C to 40°C)

  • Dimensions: 8.13 × 4.27 × 1.10 inches

  • Weight: 0.90 lbs. without packaging

  • Warranty: 3 years

The Lysora LR100G combines Gigabit performance, dual-WAN connectivity, centralized Wi-Fi management, VPN support, and powerful cloud-based tools in a compact router built for modern business networks.
