Lysora L7 Pro Wi-Fi 7 BE14000 Tri-Band Access Point

Enterprise-Grade Wi-Fi 7 Performance for High-Density Networks

The Lysora L7 Pro is a high-performance, tri-band Wi-Fi 7 access point designed for demanding enterprise environments with large numbers of connected devices and bandwidth-intensive applications.

Operating across the 2.4 GHz, 5 GHz and 6 GHz bands, the L7 Pro delivers combined wireless speeds of approximately 13.7 Gbps. Eight spatial streams, 320 MHz channel support and Multi-Link Operation provide the capacity and performance required for high-density wireless deployments.

A 2.5GbE Ethernet port and 10GbE SFP+ interface provide flexible, high-speed uplink options that help prevent wired network connections from limiting wireless performance.

Key Features

• Tri-band Wi-Fi 7 connectivity
• 2.4 GHz, 5 GHz and 6 GHz operation
• Up to 688 Mbps on 2.4 GHz
• Up to 4,323 Mbps on 5 GHz
• Up to 8,646 Mbps on 6 GHz
• Eight spatial streams
• 320 MHz channel support on 6 GHz
• 2×2 MU-MIMO on 2.4 GHz
• 3×3 MU-MIMO on 5 GHz and 6 GHz
• One 2.5GbE Ethernet port
• One 10GbE SFP+ interface
• Multi-Link Operation and 4K-QAM
• RF beamforming and band steering
• Wireless meshing support
• 802.11k, 802.11v and 802.11r roaming
• Layer 2 and Layer 3 roaming
• WPA3, 802.1X and client-isolation support
• Captive portal and bandwidth limiting
• AP and router operating modes
• Local or remote management through the Lysora App
• Unified monitoring and configuration through Lysora Cloud
• AI-powered network optimization
• NDAA compliant

Built for High-Density Wireless Environments

The L7 Pro supports up to 600 connected clients across all three frequency bands, with a recommended capacity of up to 200 associated Wi-Fi 6 or Wi-Fi 7 clients under supported configurations.

Its estimated coverage area of approximately 1,561 square feet, combined with advanced roaming and network-optimization features, makes it ideal for environments where users require fast and dependable connectivity while moving throughout the property.

Ideal Applications

• Large offices and corporate facilities
• Conference and training centers
• Hotels and hospitality properties
• Schools and universities
• Healthcare facilities
• High-density retail environments
• Entertainment venues
• Enterprise wireless networks
• Bandwidth-intensive indoor applications

Technical Specifications

• Wi-Fi standard: IEEE 802.11a/b/g/n/ac/ax/be
• Frequency bands: 2.4 GHz, 5 GHz and 6 GHz
• Maximum wireless rate: 688 Mbps at 2.4 GHz; 4,323 Mbps at 5 GHz; 8,646 Mbps at 6 GHz
• Spatial streams: Eight
• Maximum channel width: 320 MHz on 6 GHz
• Ethernet interface: One 2.5GbE port
• Fiber interface: One 10GbE SFP+ port
• Power input: PoE+ or 54V DC
• Maximum power consumption: 30W
• Maximum client count: Up to 600
• Recommended client count: Up to 200
• Coverage area: Approximately 1,561 square feet
• Mounting: Ceiling or wall
• IP rating: IP41
• Surge protection: ±2 kV
• Operating temperature: 32°F to 104°F
• Dimensions: 8.66 × 8.66 × 1.77 inches
• Weight: 2.43 pounds
• Certifications: FCC, IC and cTUVus
• Compliance: NDAA compliant

Specifications are based on Lysora’s official L7 Pro product information.
