LYSORA: LYS-CPE5 5GHz Wireless Bridge with 16dBi Built-In Antenna

Call: 800-888-8101

Fill Out Customer Application

PN / LYS-CPE5 * | Download data sheet

Lysora CPE5 – 5GHz Wireless Bridge with 16dBi Built-In Antenna

The Lysora CPE5 is a high-performance outdoor wireless bridge designed to provide reliable, long-distance network connectivity for surveillance, commercial, and remote networking applications. Featuring a built-in 16dBi high-gain directional antenna, the CPE5 delivers wireless throughput up to 867 Mbps with transmission distances of up to 5 km (3.11 miles).

Designed for point-to-point and point-to-multipoint deployments, the CPE5 supports TDMA technology and connections with up to 5 CPEs. Three Gigabit Ethernet ports provide flexible wired connectivity, while its IP55 weather-resistant enclosure allows for dependable outdoor installation. The CPE5 can be managed locally through its web interface or remotely using Lysora Cloud.

Key Features:

• 5GHz wireless bridge
• Up to 867 Mbps wireless throughput
• Built-in 16dBi high-gain directional antenna
• Long-distance wireless transmission up to 5 km / 3.11 miles
• Supports point-to-multipoint connections with up to 5 CPEs
• TDMA support for efficient wireless communication
• 3 × Gigabit Ethernet ports
• BaseStation and CPE operating modes
• Antenna alignment and spectrum scanning tools
• VLAN support
• Web and Lysora Cloud management
• Wall or pole mounting
• IP55 weather-resistant design
• Operating temperature from -22°F to 131°F
• Supports 24V Passive PoE
• NDAA compliant
• FCC, IC, and cTUVus certified

Ideal Applications:
CCTV and IP surveillance systems, building-to-building network connections, remote facilities, outdoor wireless networking, point-to-point links, and point-to-multipoint deployments.

What's Included:
CPE5 device, mounting hardware, power adapters, passive PoE injectors, user manual, and warranty card.
