Lysora LR1500XS High-Performance Cloud-Managed Multi-Gigabit Router

Powerful Multi-Gigabit Routing for High-Density Business Networks

The Lysora LR1500XS is a high-performance, rack-mountable cloud-managed router built for demanding commercial, industrial, hospitality, education, and multi-site network environments. It combines eight RJ45 Ethernet ports—including four 2.5G-capable ports—with two 10G SFP+ optical ports, providing the bandwidth and flexibility needed for high-speed internet connections, network aggregation, and fiber uplinks.

Powered by a quad-core 1.8 GHz processor with 4 GB of RAM, the LR1500XS delivers up to 4 Gbps of throughput, supports as many as 300,000 concurrent sessions, and is recommended for networks serving up to 1,500 concurrent clients. Integrated cloud management allows administrators to monitor, configure, update, and troubleshoot the router remotely through a web interface or mobile application.

Key Features

  • Eight RJ45 Ethernet ports plus two 10G SFP+ optical ports

  • Four RJ45 ports support multi-gigabit speeds up to 2.5 Gbps

  • Flexible LAN/WAN configuration supports multiple internet connections

  • Provides up to 4 Gbps of routing throughput

  • Recommended for networks with up to 1,500 concurrent clients

  • Supports as many as 300,000 concurrent sessions

  • Quad-core processor with a 1.8 GHz clock speed per core

  • 4 GB RAM, 8 GB eMMC storage, and 128 MB flash memory

  • Cloud-based remote configuration, monitoring, diagnostics, and firmware upgrades

  • Mobile-app and web-based management

  • Supports routing and wireless-controller operating modes

  • Can manage up to 1,000 compatible wireless access points

  • Integrated SD-WAN with up to 1.2 Gbps performance

  • Supports IPsec, WireGuard, OpenVPN, L2TP, PPTP, and L2TP over IPsec VPNs

  • Advanced IPv4 and IPv6 routing capabilities

  • Supports load balancing, policy-based routing, static routing, BGP, OSPF, and RIP

  • User behavior management, application control, flow control, and traffic auditing

  • Local traffic-audit log storage with SATA 3.0 hard-drive support

  • Fanless metal enclosure provides quiet, reliable operation

  • Rack-mounting brackets included

  • NDAA compliant

  • Backed by a three-year warranty

Flexible Multi-Gigabit Connectivity

The LR1500XS provides ten total network interfaces for connecting internet services, local network equipment, switches, servers, and fiber infrastructure:

  • One fixed 2.5G WAN port

  • One fixed Gigabit LAN port

  • Three configurable 2.5G LAN/WAN ports

  • Three configurable Gigabit LAN/WAN ports

  • One SFP+ optical port

  • One multi-rate 1G/2.5G/10G SFP+ optical port

The configurable LAN/WAN interfaces allow the router to support multiple internet connections, load balancing, failover strategies, and customized network designs. Up to nine ports can be assigned for LAN or WAN use, depending on the network configuration.

High-Capacity Network Performance

A quad-core processor, 4 GB of memory, and maximum throughput of 4 Gbps give the LR1500XS the performance required for networks with substantial client counts and internet traffic. Support for up to 300,000 concurrent sessions makes it suitable for environments containing large numbers of computers, mobile devices, cameras, access points, and other connected equipment.

Integrated Access-Point Management

The LR1500XS can operate in routing mode or as an access-point controller. It supports centralized management of compatible wireless access points, including:

  • Wi-Fi radio-frequency configuration

  • Client monitoring and management

  • Allowlist and blocklist controls

  • 802.1X authentication

  • AP Mesh configuration

  • Wireless Quality of Service

  • 802.11k/v roaming

  • Portal authentication

  • AP load balancing

  • Layer 2 client isolation

  • Cloud-based AP monitoring and configuration

The router supports up to eight SSIDs and can manage as many as 1,000 compatible access points in routing or AC mode.

Advanced Routing and SD-WAN

The LR1500XS includes advanced routing capabilities for multi-site and complex network deployments. Supported features include:

  • IPv4 and IPv6 static routing

  • Policy-based routing

  • URL-based routing

  • Load balancing

  • BGP

  • OSPFv2 and OSPFv3

  • RIP

  • NAT and port mapping

  • DHCP and DNS services

  • Dynamic DNS

  • IPTV

  • SD-WAN

These features allow administrators to optimize traffic paths, manage multiple internet connections, connect remote locations, and create resilient network infrastructures.

Comprehensive VPN Support

The LR1500XS supports both site-to-site and client-to-site VPN connections:

  • IPsec VPN

  • WireGuard

  • OpenVPN

  • L2TP VPN

  • L2TP over IPsec

  • PPTP VPN

Maximum listed VPN performance includes:

  • L2TP: Up to 1,150 Mbps

  • PPTP: Up to 1,450 Mbps

  • OpenVPN: Up to 300 Mbps

  • IPsec: Up to 730 Mbps

  • IPv6 IPsec: Up to 900 Mbps

  • WireGuard: Up to 1,200 Mbps

  • L2TP over IPsec: Up to 750 Mbps

  • SD-WAN: Up to 1,200 Mbps

Actual performance may vary based on configuration, traffic conditions, encryption, and connected equipment.

Network Security and Authentication

Built-in security and access-management capabilities include:

  • Access-control lists

  • IP-to-MAC address binding

  • MAC address filtering

  • Security zones

  • Local attack defense

  • Connection limiting

  • Network-sharing prevention

  • 802.1X authentication

  • PPPoE authentication

  • MAC Authentication Bypass

  • Local and cloud-based portal authentication

  • Account, voucher, QR-code, SMS, and one-click authentication

  • Third-party WISPr and WiFiDog portal support

Cloud Management and Monitoring

Lysora cloud management gives administrators remote visibility and control over the router and connected network. Available capabilities include:

  • Remote device monitoring

  • Remote restart

  • Cloud-based firmware upgrades

  • Mobile-app management

  • Web-based management

  • Remote fault diagnosis

  • Self-organizing network deployment through code scanning

  • Syslog, SNMP, and RLOG support

  • NTP client support

  • HTTPS management access

  • Automatic fault diagnosis

Ideal Applications

  • Large commercial offices

  • Warehouses and distribution centers

  • Hotels and hospitality properties

  • Schools and educational campuses

  • Healthcare facilities

  • Retail stores and multi-location businesses

  • Industrial and manufacturing environments

  • High-density wireless networks

  • Managed service provider deployments

  • Surveillance and security networks

  • Fiber-connected network infrastructures

  • Multi-WAN and SD-WAN installations

Technical Specifications

  • Model: LR1500XS

  • Product Type: Cloud-managed multi-gigabit router

  • Total RJ45 Ports: 8

  • 2.5G-Capable RJ45 Ports: 4

  • Gigabit RJ45 Ports: 4

  • Optical Ports: 2

  • SFP+ Speed Support: Up to 10 Gbps

  • Maximum LAN Ports: 9

  • Maximum WAN Ports: 9

  • Fixed LAN Ports: 1

  • Fixed WAN Ports: 1

  • Configurable LAN/WAN Ports: 8

  • Maximum Throughput: 4,000 Mbps

  • Maximum Concurrent Sessions: 300,000

  • Recommended Concurrent Clients: 1,500

  • Processor: Quad-core, 1.8 GHz per core

  • RAM: 4 GB

  • Flash Memory: 128 MB

  • eMMC Storage: 8 GB

  • Hard-Drive Support: One standard SATA 3.0 HDD

  • Maximum Managed Devices: 128

  • Maximum Managed Access Points: 1,000

  • Maximum VLANs: 128

  • Maximum SSIDs: 8

  • Power Input: 100–240V AC, 50/60 Hz

  • Maximum Power Consumption: 18 W

  • Cooling: Fanless, natural convection

  • Enclosure: Metal

  • Mounting: Desktop or rack mounting

  • Operating Temperature: 32°F to 104°F (0°C to 40°C)

  • Storage Temperature: –40°F to 158°F (–40°C to 70°C)

  • Operating Humidity: 10%–90% RH, non-condensing

  • Dimensions: 440 × 210 × 43.6 mm (approximately 17.32 × 8.27 × 1.72 inches)

  • Weight: 6.61 lb without packaging

  • Packaged Weight: 8.42 lb

  • Warranty: Three years

  • NDAA Compliant: Yes

  • Certifications: FCC, IC, cTUVus

  • Safety Standard: UL 62368-1

Package Contents

  • One LR1500XS cloud-managed router

  • Two rack-mount brackets

  • Four rubber feet

  • One power cord

  • One power-cord retention clip

  • Eight M4 mounting screws

  • User manual

  • Warranty card

The Lysora LR1500XS delivers the multi-gigabit connectivity, routing capacity, cloud management, VPN support, and wireless-network control required for high-density professional network deployments.
