SeeStation DVR Kit 8 Channel 960H With 8 Each 800TVL BLACK Cameras

Brand SEESTATION (NEW)

You must be logged in to see the price and add to cart.

 PN / SS-S015V08120K-8B *

 (Supports Max 3 Tb SATA Port) Hard Drive Not included

8 Channel Professional Grade DVR KIT with 4 IR Bullet and 4 IR Dome Cameras. Black Metal Housing. Compatible with PC or Apple / MAC operating systems. Remote View on PC or Mobile Phone, Tablet or similar device. This 960H Hi-Resolution system comes with Mouse, IR Remote Control.

Includes:
* 1 PCS, 8CH 960H All Real Time H.264 DVR,

H.264 compression, with HDMI, with RS-485 & OSD menu
Supports DHCP, PPPOE, FTP, DNS, DDNS, NTP,
Supports mobile phone live view
Includes mouse and remote control.
Supports PC & Apple Mac system viewing.

* 4 Each Outdoor Weather Resistant Bullet Cameras

Color 1/3" 960H CMOS DSP
800TVL Bullet Cameras
IR CUT Filter
3.6 fixed lens 0Lux Lens
24Pcs IR LEDs / 20M IR Distance
All oriented bracket,
IP66
DC12V

* 4 Each Outdoor Weather Resistant Dome Cameras

Color 1/3" 960H CMOS DSP
800TVL Bullet Cameras BLACK
IR CUT Filter
3.6 fixed lens 0Lux Lens
24Pcs IR LEDs / 20M IR Distance
All oriented bracket,
IP66
DC12V

* (Supports Max 3 Tb SATA Port) (Not Included)
* 8  20M BNC+DC CCTV Cables
* 1 Power Splitter
* 1 Power Adapter
* 1 IR Remote Controller
* 1 Mouse
*  Color Package
*  1 Year Warranty


 Feature
· Supports Symbian, Windows Mobile, Iphone
· Supports Android, BlackBerry, realtime recording
· Support Apple Mac system viewing
· With unique flash board showing date, time, etc
· 4CH 960H all real time
· 8CH 960H all real time
· 16CH Full D1 all real time
· With HDMI
· VGA Output at 1920 x 1080
· Support WIFI & 3G
· Support mobile phone live view via 3G net
· With the unique black box technology
· Monitor the whole run process of the equipment
· Greatly reduce the maintenance costs
· H.264 main profile compression algorithm
· Video denoising reduced stream 30% lower relatively
· Mobile’s multi-monitor, also emulational mobile phone
· Support USB2.0
· The User Friendly operation system is similar to WINDOWS
· Powerful mouse’s right button menu function
· Powerful network services
· Support DHCP, PPPOE, FTP, DNS, DDNS, NTP
· EMAIL, IP permissions, IP searches, Alarm Center
· Full Matching (WEB, Client, SDK)
· Easy to achieve interoperability
· Perfect protection circuit, unique triple watchdog
· Low power consumption to assure never out of work
· Multiple language OSD available
· Support PTZ and lens control and alarm
· Support multiple channels playback at the same time
· Support 1 piece of 3,000 GB SATA HDD
· Built in 3322, Oray, dyndns myq-see
· Built in DDNS free domain



Specification
Model No. 16 Channel 8 Channel 4 Channel
Main Processor High performance embedded microcontroller
Operating System Embedded LINUX
System Resources multi-channel real-time recording and playback, multi-channel net operation for several persons, USB backup
Operation Interface 16-bit true color graphical menu interface and mouse support
Menu Display 1/4/8/9/16 screen 1/4/8/9 screen 1/4 screen
Video Standards PAL(625 line, 50 f/s); NTSC (525 line, 60 f/s)
Surveillance Quality PAL, 960H /D1(704×576); NTSC, 960H /D1(704×480)
Playback Quality PAL, 960H /D1(704×576); NTSC, 960H /D1(704×480)
Code Ability 400/480fps  200/240fps   100/120fps
16CH D1@25F/S/CH 8CH D1/960H@25F/S/CH  4CH 960H@25F/S/CH
Motion Detection Zones:396(22*18)detection zones, many levels of Sensitivity setting
Audio Compression G711A
Bidirectional Talk Support
Recording Mode Manual>Alarm>Dynamic Detection>Timing
Playback 4CH*960H/1CH*D1 4CH*D1/2CH*960H 4CH
Search Mode Time/Date, Alarm, Motion Detection & exact search(accurate to second)
Space Occupation Audio: 28.8MB/H   Video: 25~450MB/H
Video Storage Hard disk, SD card(optional), and net
Backup Mode Network burn, mobile Hard disk and USB burn
Video Input 16 CH, BNC, 1.0Vp-p,75Ω 8 CH, BNC, 1.0Vp-p,75Ω 4CH, BNC, 1.0Vp-p,75Ω
Video Output 1 channel, BNC, 1.0Vp-p,75Ω and 1 VGA output; 1 channel HDMI Output (1920*1080P)
Audio Input 8 CH 4 CH
Audio Output 1 CH, RCA, 200-3000mV,5KΩ
Alarm Input 4 CH N/A
Alarm Output 1 CH N/A
Net Interface RJ-45 (10M/100M)
PTZ Control 1 RS485
USB Interface 2 Ports
With HDMI YES




Supports 2 HDD Max 6 TB SATA  (Not Included)

SeeStation uses and recommends only Western Digital "WD Purple" Hard Drives for all Surveillance Recorders.
