PN / UNV-HB-7099-S *
The HB-7099-S is a pluggable PC Module for use with the Uniview Interactive Displays.
Overview
The HB-7099-S is a pluggable PC Module for use with the Uniview Interactive Displays.
| Model | HB-7099-S |
| CPU | Intel® I7-8550U |
| RAM | 8G |
| SSD | 256G |
| Chipset | Intel Coffee Lake-U |
| Display | HDMI:4096x2160@30Hz ,OPS:4096x2160@60Hz |
| Network | Integrated 10/100/1000M Adaption, Wireless-AC 3165 |
| OS | Windows10(not active) |
| Interface | HDMI × 1,USB 3.0 × 2,USB 2.0 × 2,Type-C × 1,LAN × 1,WIFI × 2 |
| Audio | |
| Audio Input | 3.5 mm mini-jack×1 |
| Audio 0utput | 3.5 mm mini-jack×1 |
| General | |
| Power supply | DC 12~19V |
| Operation Temperature | 0°C ~ 40 °C |
| Storage Temperature | -20°C ~60°C |
| Dimension (L×W×H) | 119.5mm × 180.0 mm × 30.0mm |
| Weight | 1kg |
| Accessory | |
| Standard | WIFI Antenna × 2, M3 Screw × 2 |
